Hot Cell

Product Dispenser Research
Dispensing
Dispenser Hotcell The NUCLOCK N2 is a hot cell made for radiopharmaceuticals dispensing to be carried out in accordance with the GMP standards thanks to air tight, ventilation system with HEPA filters, absolute filtering and inside surfaces quality.

The main features of the N2 series :

Ventilation
- Inlet HEPA filters
- Outlet HEPA
- In order to avoid any influence on the local laminar flow of dispensing unit, the atmosphere pureness inside the box is assured by flat filters (both inlet and outlet) and a high quantity of air changes per hour.

Accessories
- Air-tight and minimum volume duct with double door (ball valves) for vial extraction without altering cell sterility.
Dispensing
Specification
Shielding Lead thickness : 50, 75, 100mm on all sides
Internal view CCTV or Lead glass window on main door
Ventilation - Air quality: Class A, B, C
- Inlet filter: HEPA (Ei≥99.97%)
- Outlet filter: Charcoal
Materials introduction & extraction Double door air tight system for vials extraction Extractable trolly for the lead containers
Dimensions & Characteristics External dimensions : 1400(W) x 1300(D) x 2700(H)mm
Inner dimensions : 850(W) x 850(D) x 800(H)mm
Weight : about 9000kg
Inlet Air : 4kg/cm2
Inlet N2:7kg/cm2
Vacuum : 400mmHg
Utility Three phase 380V, 5kW / Single phase 220V, 2kW
Main door Up-down type
- Automatic up-down mobile door activated by motor installed low part of cells
Swing type
- Manually operated Hinged Shielding door
Option Dose - lift system
Tong with booting
Hand Glove
Pre-chamber
* All the specifications illustrated above shall be tailored so as to fit into requests made by end-users.
